BRP EVINRUDE E-TEC 200 - OIL RECIRCULATION DIAGRAMS

160
OILING SYSTEM
OIL SUPPLY DIAGRAMS
250 – 300 HP (3.4 L) MODELS
Primary oil manifold
delivers oil to
crankcase fittings
3
1. Cylinder 1
2. Cylinder 2
3. Cylinder 3
4. Cylinder 4
5. Cylinder 5
6. Cylinder 6
6
5
4
7
2
1
8
6
6
2
3
4
5
6
1
1. Cylinder 2
2. Cylinder 4
3. Cylinder 6
4. Cylinder 1
5. Cylinder 3
6. Cylinder 5
Rear oil pump delivers
oil to cylinder sleeves
1
2
3
4
5
6
008433
1.
2.
3.
4.
5.
6.
7.
8.
Oil tank assembly
Oil pick-up
Oil supply hose
In-line oil filters
Oil injector assembly
Oil distribution hoses
Oil pressure sensor
Rear oil pump
