214
EVINRUDE ICON REMOTE CONTROL SYSTEM
ICON SYSTEM FAULT CODE CHART
150
Throttle Actuator Motion
Fault
The ESM tries to move the
throttle actuator, but it will not
attain the commanded posi-
tion.
This is caused by a motion or
over-current error from the
actuator.
The fault message is sent
from the ESM to the out-
board’s EMM.
FORWARD or REVERSE LED
flashes (depending on gear
position when fault occurred).
With the remote control lever in
NEUTRAL, the NEUTRAL LED
of the affected engine continues
to flash one time per second.
Throttle link arm from ICON add-
on kit is not assembled to the out-
board.
Throttle linkage components are
damaged or their movement is
blocked.
Starter cable is not correctly
routed behind the actuator
mounting plate.
Throttle actuator has failed.
Throttle Actuator Motion Check
(Chart 17)
151
Shift Actuator Sensor Fault
The ESM has lost the shift
actuator position sensor sig-
nal.
The fault message is sent
from the ESM to the out-
board’s EMM.
All gear position LED’s flash five
times per second.
With the remote control lever in
NEUTRAL, the NEUTRAL LED
of the affected engine continues
to flash five times per second.
RFI due to excessive spark plug
gap, damaged or worn spark
plugs.
The actuator and the ESM are not
connected.
The actuator and ESM connec-
tors are damaged.
The wiring of the actuator and
ESM connectors are in the wrong
locations.
Shift actuator position sensor
failed.
Shift Actuator Sensor Check
(Chart 18)
152
Shift Actuator Motion Fault
The ESM tries to move the
shift actuator, but it will not
attain the commanded posi-
tion.
This is caused by a motion or
over-current error on the actu-
ator itself.
The fault message is sent
from the ESM to the out-
board’s EMM.
FORWARD or REVERSE LED
flashes (depending on gear
position when fault occurred).
With the remote control lever in
NEUTRAL, the NEUTRAL LED
of the affected engine continues
to flash one time per second.
ICON shift link is not assembled
to the outboard.
Shift linkage components are
damaged or their movement is
blocked.
Shif
t stroke
is not calibrated cor-
rectly.
Shift actuator has failed.
Shift Actuator Motion Check
(Chart 20)
Fault Code Description LED Indicators
Possible Causes and
Flowchart Reference
