220
POWERHEAD
POWERHEAD REMOVAL
Remove trim/tilt harness from clamp.
Remove pin and wa sher from shif t rod lever to
release the lower shift rod.
Remove flywheel. Refer to Flywheel Removal on
p. 109.
Securely fasten L ifting Fixture, P/N 3 96748, to
crankshaft threads.
Fasten appropriate chain hook to eye of tool a nd
support weight of powerhead with hoist.
Remove all powerhead retaining screws and nuts.
Remove the rear powerhead nut.
Use a suitable tool to carefully separate the pow-
erhead from exhaust housing.
IMPORTANT: Do not damage the powerhe ad
adapter mating surfaces when separating.
1. Trim harness
2. Clamp
005041
1. Shift rod pin 004241
48758
1. Screws and nuts 004240
1. Rear powerhead nut 004252
