POWERHEAD ASSEMBLY
Lightly coat the outside edge of a new crankshaft
seal with Gasket Sealing Compound. Use Se al
Installation T ool, P/N 3254 53, to install seal in
lower crankcase hea d with extended lip of se al
facing down. Coat se al lip s with Triple-Guard
grease.
Lightly coat two new O-rings with Gasket Sealing
Compound and inst all on lo wer crankca se he ad.
Keep sealer away from oil passage.
Use threaded rods or Guide Rods, P/N 383175, to
align retainer plate with crankcase hea d. Slide
crankcase head onto crankshaft u ntil sea ted
around lower main bearing.
Install new seals on th e fo ur be aring ret ainer
screws. Appl y Nut Lock t o th e threads o f t he
screws and tighten to a torque of 96 to 120 in. lbs.
(11 to 13.5 N·m).
Lightly coat the outside edge of a new uppe r seal
with Gasket Sealing Compound. Use the fla t end
of Sea l Inst allation T ool, P/N 325 453, to inst all
seal flush in upp er cran kcase h ead with the lip
facing down. Coat the seal lip with Triple-Guard
grease.
1. Seal, extended lip DRC5798
1. Oil passage 004132
000826
000827
1. Seal installer, P/N 325453 49597
