BRP EVINRUDE E-TEC 200 - Page 404

A
B C
5
1 2
3
4
5
1 2
3
4
008051
I-Command Keyswitch/TNT Wiring Harness
Ground (B-)
A. Trim down B. Trim up C. Trim sender
5. Battery + (12V) 1. Stop circuit 2. Start solenoid 3. Ground (B-) 6. Choke 4. Switched B+ (12V)
A
B C
Switched B+ (12V)
47 ohm 5 watt resistor
10 Amp Fused
B+ (12V)
