51-6 Fuel injector circuit OPEN LED 2: ON (Running) - 10 seconds
Last digit indicates affected cylinder.
Check injector/circuit resistance—2 to 3
Ω @ 72°F (22°C).
57 High RPM with low TPS setting
33
LED 3: FLASHING
CHECK ENGINE
(FLASHING)
10 seconds
TPS < 5% and RPM > 3000. Engine SHUTDOWN. Will NOT restart until code has been cleared. The problem could be caused
by uncontrolled fuel entering the engine. DO NOT attempt to start the outboard until the problem has been found and repaired.
58 Operating temperature not reached (port) LED 3: OFF (Cranking) / ON (Running) - 10 minutes
Engine temperature < 122°F (50°C) with engine speed < 1000 RPM.
Check thermostat and pressure relief valve.
59 Operating temperature not reached (stbd) LED 3: OFF (Cranking) / ON (Running) - 10 minutes
Engine temperature < 122°F (50°C) with engine speed < 1000 RPM.
Check thermostat and pressure relief valve.
61-6 Fuel injector circuit SHORTED LED 2: ON (Running) - 10 seconds
Last digit indicates affected cylinder.
Check injector/circuit resistance—2 to 3
Ω @ 72°F (22°C).
67
Engine Temperature Sensor circuit fault
(stbd)
LED 3: OFF (Cranking) / ON (Running) - 10 seconds
Engine Temperature < -13° F (-25° C), or > 329° F (165° C).
Check 5 V circuit and ground (NEG), and sensor resistance—9000 to 11000
Ω @ 77°F (25°C).
68 Engine Temperature BELOW range (stbd) LED 3: OFF (Cranking) / ON (Running) - 10 seconds Engine Temperature < -4° F (-20° C). Check engine temperature and sensor resistance.
69 Engine Temperature ABOVE range (stbd)
3
LED 4: ON (Running) WATER TEMP/HOT 3 seconds
60° V4 & V6 Models: Engine Temperature > 194°F (90°C) above 3000 RPM activates S.A.F.E.
90° V6 Models: Engine Temperature > 185° F (85° C) above 2000 RPM for 60 seconds activates warning light and horn;
90° V6 Models: Engine Temperature > 194°F (90°C) above 2000 RPM for 3 seconds activates S.A.F.E.
Engine limited to 1200 RPM. Check cooling system.
70
Engine Temperature ABOVE range (stbd)–
low speed
3
LED 4: ON (Running) WATER TEMP/HOT 3 seconds
60° V4 & V6 Models: Engine Temperature > 230° F (110° C) below 3000 RPM
90° V6 Models: Engine Temperature > 212° F (100° C) below 2000 RPM
71 Oil pressure sensor circuit fault detected LED 3: OFF (Cranking) / ON (Running) - 10 seconds < 0.15 V , > 4.85 V
72 Oil pressure BELOW expected range LED 3: OFF (Cranking) / ON (Running) - 10 seconds < 0.4 V
73 Oil pressure ABOVE expected range LED 3: OFF (Cranking) / ON (Running) - 10 seconds > 4.6 V
74 Water pressure sensor circuit fault detected LED 3: OFF (Cranking) / ON (Running) - 10 seconds < 0.15 V , > 4.85 V. EMM water pressure option (I-Command) active
75 Water pressure BELOW expected range LED 3: OFF (Cranking) / ON (Running) - 10 seconds < 0.4 V. EMM water pressure option (I-Command) active
76 Water pressure ABOVE expected range LED 3: OFF (Cranking) / ON (Running) - 10 seconds > 4.6 V. EMM water pressure option (I-Command) active
77 S.A.C. overcurrent fault
3
LED 1: OFF (Key On) / ON (Running) - 10 instances SAC current > 2 amps and/or < 20 V. Check for shorted 55 V wiring (injector circuits). Check for pinched or chafed wiring.
78 Sensor supply voltage fault
3
LED 3: OFF (Cranking) / ON (Running) - 10 seconds Sensor voltage < 4.75 V. Check sensors and related wiring. Check for pinched or chafed wiring.
79 Starter solenoid circuit OPEN LED 3: OFF (Key On) CHECK ENGINE 10 seconds Check starter solenoid circuit for continuity (key switch OFF) and for 12 V with key switch ON.
81-6 Ignition timing circuit OPEN LED 2: ON (Running) - 16 instances
Last digit indicates affected cylinder.
EMM counts failed ignition events (crankshaft revolutions). Check circuit resistance.
87 Exhaust pressure circuit fault
3
LED 3: OFF (Cranking) / ON (Running) - 10 seconds < -85 in. water or > 85 in. water. Check for plugged or pinched hose or exhaust fitting.
88 Exhaust pressure BELOW expected range
3
LED 3: OFF (Cranking) / ON (Running) - 10 seconds <-40 in. water
89 Exhaust pressure ABOVE expected range
3
LED 3: OFF (Cranking) / ON (Running) - 10 seconds > 80 in. water
91 Fuel pump circuit OPEN LED 2: ON (Running) - 10 seconds Check pump/circuit resistance—2 to 3
Ω @ 77°F (25°C).
92 Exhaust valve solenoid OPEN (V4) LED 2: ON (Running) - 10 seconds Refer to exhaust valve relay tests.
94 Fuel pump circuit SHORTED LED 2: ON (Running) - 2 seconds
Check pump/circuit resistance—2 to 3
Ω @ 77°F (25°C).
97 Intermittent switched B+ detected LED 3: ON (Running) - 10 seconds Switched battery voltage < 7 V. Check connections and wiring
101-
6
Ignition timing circuit SHORTED LED 2: ON (Running) -
9 events at low RPM,
3 events at high RPM
Last digit indicates affected cylinder.
EMM counts failed ignition events. Check wiring. Test with known good ignition coil.
107 ICON control communication error
3
- CHECK ENGINE Immediate Cycle master power switch off and back on. Check ICON 10 Amp fuse, buss cables, and ESM to EMM connections.
108 ICON system fail-safe mode
3
- CHECK ENGINE 2 seconds ICON control head commands EMM to activate S.A.F.E. Check other ICON codes.
109 ICON control head failure
3
- CHECK ENGINE 2 seconds Cycle master power switch off and back on. See Evinrude ICON Installation Guide.
110 ICON trim switch communication error - - 2 seconds Cycle master power switch off and back on. Check harness between panel and control.
111 ICON ESM communication error
3
- CHECK ENGINE 2 seconds Cycle master power switch off and back on. Check ICON buss cable connections. See Evinrude ICON Installation Guide.
149 ICON throttle actuator sensor fault
3
- CHECK ENGINE 2 seconds
Check actuator harness and connections. Check for RFI from excessive spark plug gap. See Evinrude ICON Installation
Guide.
150 ICON throttle actuator motion fault
3
- CHECK ENGINE 2 seconds Cycle master power switch off and back on. Check for throttle linkage for obstructions. Check harnesses.
151 ICON shift actuator sensor fault
3
- CHECK ENGINE 2 seconds
Check actuator harness and connections. Check for RFI from excessive spark plug gap. See Evinrude ICON Installation
Guide.
152 ICON shift actuator motion fault - CHECK ENGINE 2 seconds Cycle master power switch off and back on. Check actuator calibration. Check harnesses.
NOTE: Always note service codes before clearing codes. Clear stored codes using diagnostic software. Clearing some codes requires turning EMM “OFF” and then “ON” again.
CODE
EMM CIRCUIT/SENSOR
INTERNAL
SENSOR
S.A.F.E
SHUT
DOWN
EMM LED DISPLAY
DASHBOARD
GAUGE WARNING
DISPLAY
TIME TO
ACTIVATE
SENSOR: CIRCUIT VOLTAGE / RESISTANCE (Ω) / INFORMATION
page 2
Rev 10/10
