71
ENGINE MANAGEMENT MODULE (EMM)
EMM SERVICING
4
Installation
Align slots in starboard side of EMM case with iso-
lator mounts o n cylinder block. Slide EMM into
position.
Install two EMM retaining screws. Tighten screws
12 to 16 in. lbs. (1.5 to 2 N·m).
Install J1-A, J1-B, and J2 connectors.
Install exhaust pressure hose and cooling h oses.
Secure with tie straps.
1. EMM mounting slots
2. Isolator mounts
006968
1. EMM mounting screws 006967
