Technical Data
4.5 Sample Usage
SampleXpress can handle any type of sample with standard spinner geometry:
• Standard NMR tubes (3-10 mm).
• Melted reference samples.
• Match spinner (1, 1.7, 2, 2.5, 3, 4, 4.25, 5 mm).
• Shuttle POM for sample tubes 1-1.7 mm.
• Dummy samples.
• Samples with or without horizontal barcode.
The sample is handled at the spinner only!
Figure 4.2 Samples Allowed: Maximum Height 7“ (180 mm)
