Operation
9.9 Working in Manual Mode
The SampleXpress can be used without a cassette, but the spectroscopy magnet has to
be loaded manually.
Figure 9.48 Sample Transfer Position
Inserting the sample manually into the magnet:
1. Wait until the outstanding job is completed.
The lamp indicator switches to green.
2. Remove cassette (see section "Removing
the Cassette" on page 80).
3. Switch the SampleXpress off (see section
"Switching Off the Device" on page 59).
4. The sample can be inserted manually into
the BST at the sample NMR Access Posi-
tion, just as it was inserted before the
SampleXpress device was mounted.
WARNING
Danger of injury from an unexpected restart!
In the event of an unexpected restart of the power supply during manual mode, there
is a danger of serious injuries for persons in the danger zone. The gripper grips the
spinner with the sample with its claws. If the cassette is not inserted, the claws can
shear and crimp the limbs.
f Switch off all power supplies before starting work and make sure they cannot be
switched on again.
f Do not put your fingers into the small opening where the gripper is behind.
