Operation
9.2 Main Display
The main display screen shows all the information necessary during processing.
Main Screen in Single Access Mode
Figure 9.1 Main Screen Example in Single Access Mode
2
1
3
4
Position Function
1 Message display.
2 Displays the cassette with its 60 positions.
• Gray positions are empty positions.
• White positions are loaded with samples.
3 Information about Operator Access Position and Sample Down.
4 Touch screen buttons.
