BT Micro Owner’s Manual

Door Intercom

The door intercom is connected to extension 23.

Connect the single pair from the door intercom to the AB

connections on extension 23.

The system must be programmed to recognise the Door

intercom See page 183 for programming via a featurephone

and page 99 for configuration via the Web Management

application.

Power Fail Telephone

Connect a standard analogue telephone to the Power Fail

connector. When the BT Micro is switched off the analogue line (Line

1) is switched through to this phone and you can make and receive

calls on it until the power is restored.

Wall hook when the

Featurephone is desk

mounted

Wall hook when the

Featurephone is wall

mounted.

Mounting

screw

Door intercom

bracket
