3-10 2002 Buell P3: Engine
HOME
NOTE
The remaining steps are required to complete engine
removal.
15. Place jack under the motor. Use jack to lower motor.
16. Move jack forward.
17. Place wooden cradle under engine.
NOTE
See Figure 3-9. Remove rear master cylinder before remov-
ing sprocket cover.
18. Remove sprocket cover. See 2.22 SPROCKET COVER.
19. See Figure 3-9. Disconnect screws at brake fluid reser-
voir, master cylinder and brake line bracket (items 1, 3
and 6).
20. Move belt on rear sprocket off pulley toward inside of
motorcycle.
21. See Figure 3-10. Remove right side rider footpeg bracket
assembly. See 2.21 FOOTPEGS AND FOOTPEG SUP-
PORT BRACKETS.
22. Introduce freeplay and remove clutch cable at hand lever
location. See 6.4 CLUTCH.
23. See Tabl e 3-3. Disconnect the following electrical items:
Figure 3-9. Brake Line Assembly
1. Screw
2. Brake fluid reservoir
3. Screw
4. Brake line bracket
5. Brake line
6. Screw
7. Master cylinder
8. Spacer
1
3
6
7
8
2 54
a0017x3x
Figure 3-10. Footpeg Bracket Assembly
1. Frame
2. Locknut
3. Washer
4. Spacer
5. Footrest support bracket
6. Clevis pin
7. Footpeg
8. Cotter pin
9. Index plate
10. Spacer
a0016x3x
1
2
3
4
5
6
8
7
10
9
