7-10 2002 Buell P3: Electrical
HOME
Figure 7-8. Continuous or No Spark At Spark Plug
3.0-3.5 VDC
YES
Measure Voltage On Connector [134B] Between Socket C,
(GY), And Socket B, (BK).
Is Voltage 11-13 VDC?
NO
Is Bank Angle Sen-
sor Correctly
Installed?
Repair Open In (GY) Wire Between
Bank Angle Sensor And Ignition Fuse
Are Ferrous Metals Located
Within 1/4” Of Sides, Face, Or
Top Of Bank Angle Sensor?
YES
NO
Install Properly
Return To Origi-
nal Configuration.
NO
Replace Bank
Angle Sensor.
YES
5007
5013
To Next Page
