LED Colour Assignments
Withtheclassicvariants(24VDC,120VAC,AS-i,DeviceNet),thesettingcanbechangedbyaservice
technician, if necessary.
The parameter values and the assigned display priority are listed in
“Table18”.
Parameter
“PRIO”
(highest) priority 1 Priority 2 Priority 3 (lowest) priority 4
1 S1 S2 S3 S4
2 S1 S2 S4 S3
3 S1 S3 S2 S4
4 S1 S3 S4 S2
5 S1 S4 S2 S3
6 S1 S4 S3 S2
7 S2 S1 S3 S4
8 S2 S1 S4 S3
9 S2 S3 S1 S4
10 S2 S3 S4 S1
11 S2 S4 S1 S3
12 S2 S4 S3 S1
13 S3 S1 S2 S4
14 S3 S1 S4 S2
15 S3 S2 S1 S4
16 S3 S2 S4 S1
17 S3 S4 S1 S2
18 S3 S4 S2 S1
19 S4 S1 S2 S3
20 S4 S1 S3 S2
21 S4 S2 S1 S3
22 S4 S2 S3 S1
23 S4 S3 S1 S2
24 *) S4 S3 S2 S1
25
particular logic, see “Table19”
Table 18: Display priorities when position feedback overlaps - can be selected using parameter “PRIO”
*)Factorysettings:“PRIO24”
WhenthepositionfeedbackisfromS4(externalinitiator),notewhethertheexternalinitiatoractsasan“Opener”
(NCcontact)orasa“Closer”(NOcontact)–see“Table8:Positionfeedbackoftheexternalinitiator(S4/S4IN)
dependsonthemodeofoperating”onpage138
If the factory setting of S4IN
(normallyopencontact=NO)istobechanged,thiscanbedoneforIO-Link
and büS/CANopen variants via software using the sensor parameter “Circuit Function External Initia tor
