J No. Sym-
bol
Name Relay con-
nector
J No. Symbol Name Remarks
J710 UN6 Fixing Relay PCB J301
3
SR9 Fixing Pressure Release Sensor
J710 UN6 Fixing Relay PCB J301
4
SR8 Fixing Delivery Sensor
J924 UN13 Main Controller PCB J951 UN14 Control Panel NFC PCB
J961 UN20 NFC PCB J956 UN14 Control Panel NFC PCB MF727Cd
w / 726Cdw
4. Disassembly/Assembly
115
To Next Page
