COPIER > ADJUST > CCD
Item Description
Details To adjust the offset of the CIS (Front) when reading B&W original.
When replacing the Main Controller PCB / clearing the RAM data, enter the value of service label.
Use case When replacing the Main Controller PCB / clearing RAM data
Adj/set/operate method Enter the setting value, and then press Apply key.
Display/adj/set range 0 to 255
Default value 8
Related service mode COPIER > FUNCTION > CCD > BW-AGC
OFST-CL0
Title Adjustment of CIS (Rear) at color reading
Details To adjust the offset of the CIS (Rear) when reading color original.
When replacing the Main Controller PCB / clearing the RAM data, enter the value of service label.
Use case When replacing the Main Controller PCB / clearing RAM data
Adj/set/operate method Enter the setting value, and then press Apply key.
Display/adj/set range 0 to 255
Default value 8
Related service mode COPIER > FUNCTION > CCD > CL-AGC
OFST-CL1
Title Adjustment of CIS (Center) at color reading
Details To adjust the offset of the CIS (Center) when reading color original.
When replacing the Main Controller PCB / clearing the RAM data, enter the value of service label.
Use case When replacing the Main Controller PCB / clearing RAM data
Adj/set/operate method Enter the setting value, and then press Apply key.
Display/adj/set range 0 to 255
Default value 8
Related service mode COPIER > FUNCTION > CCD > CL-AGC
OFST-CL2
Title Adjustment of CIS (Front) at color reading
Details To adjust the offset of the CIS (Front) when reading color original.
When replacing the Main Controller PCB / clearing the RAM data, enter the value of service label.
Use case When replacing the Main Controller PCB / clearing RAM data
Adj/set/operate method Enter the setting value, and then press Apply key.
Display/adj/set range 0 to 255
Default value 8
Related service mode COPIER > FUNCTION > CCD > CL-AGC
GAIN-BW0
Title Adjustment of gain at B&W reading
Details To adjust the gain when reading B&W original.
When replacing the Main Controller PCB / clearing the RAM data, enter the value of service label.
Use case When replacing the Main Controller PCB / clearing RAM data
Adj/set/operate method Enter the setting value, and then press Apply key.
Display/adj/set range 1 to 255
Default value 64
Related service mode COPIER > FUNCTION > CCD > BW-AGC
GAIN-CL0
Title Adjustment of gain at color reading
Details To adjust the gain when reading color original.
When replacing the Main Controller PCB / clearing the RAM data, enter the value of service label.
Use case When replacing the Main Controller PCB / clearing RAM data
Adj/set/operate method Enter the setting value, and then press Apply key.
Display/adj/set range 1 to 255
Default value 64
Related service mode COPIER > FUNCTION > CCD > CL-AGC
LED-BW-R
Title Adjustment of LED light-up time (R) at B&W reading
