COPIER > ADJUST > CCD
Item Description
Details To adjust the red color LED lighting time when reading B&W original.
When replacing the Main Controller PCB / clearing the RAM data, enter the value of service label.
Use case When replacing the Main Controller PCB / clearing RAM data
Adj/set/operate method Enter the setting value, and then press Apply key.
Display/adj/set range 0 to 2432
Default value 1000
Related service mode COPIER > FUNCTION > CCD > CL-AGC
LED-BW-G
Title Adjustment of LED light-up time (G) at B&W reading
Details To adjust the green color LED lighting time when reading B&W original.
When replacing the Main Controller PCB / clearing the RAM data, enter the value of service label.
Use case When replacing the Main Controller PCB / clearing RAM data
Adj/set/operate method Enter the setting value, and then press Apply key.
Display/adj/set range 0 to 2432
Default value 1000
Related service mode COPIER > FUNCTION >CCD > BW-AGC
LED-BW-B
Title Adjustment of LED light-up time (B) at B&W reading
Details To adjust the blue color LED lighting time when reading B&W original.
When replacing the Main Controller PCB / clearing the RAM data, enter the value of service label.
Use case When replacing the Main Controller PCB / clearing RAM data
Adj/set/operate method Enter the setting value, and then press Apply key.
Display/adj/set range 0 to 2432
Default value 1000
Related service mode COPIER > FUNCTION > CCD > BW-AGC
LED-CL-R
Title Adjustment of LED light-up time (R) at color reading
Details To adjust the red color LED lighting time when reading color original. When replacing the Main Controller
PCB / clearing the RAM data, enter the value of service label.
Use case When replacing the Main Controller PCB / clearing RAM data
Adj/set/operate method Enter the setting value, and then press Apply key.
Display/adj/set range 0 to 2432
Default value 1200
Related service mode COPIER > FUNCTION > CCD > BW-AGC
LED-CL-G
Title Adjustment of LED light-up time (G) at color reading
Details To adjust the green color LED lighting time when reading color original. When replacing the Main Con-
troller PCB / clearing the RAM data, enter the value of service label.
Use case When replacing the Main Controller PCB / clearing RAM data
Adj/set/operate method Enter the setting value, and then press Apply key.
Display/adj/set range 0 to 2432
Default value 1200
Related service mode COPIER > FUNCTION > CCD > BW-AGC
LED-CL-B
Title Adjustment of LED light-up time (B) at color reading
Details To adjust the blue color LED lighting time when reading color original. When replacing the Main Con-
troller PCB / clearing the RAM data, enter the value of service label.
Use case When replacing the Main Controller PCB / clearing RAM data
Adj/set/operate method Enter the setting value, and then press Apply key.
Display/adj/set range 0 to 2432
Default value 1200
Related service mode COPIER > FUNCTION > CCD > BW-AGC
