■ PASCAL
COPIER > ADJUST > PASCAL
Item Description
OFST-P-Y
Title Y density adj at test print reading
Details To adjust the offset of Y color test print reading signal at Auto Adjust Gradation (Full Adjust).
When replacing the Main Controller PCB / clearing the RAM data, enter the value of service label.
As the greater value is set, the image after adjustment gets darker.
Use case When replacing the Main Controller PCB / clearing RAM data
Adj/set/operate method Enter the setting value (switch negative / positive by * key) and press Apply key.
Caution After the setting value is changed, write the changed value in the service label.
Display/adj/set range -32 to 32
Default value 0
OFST-P-M
Title M density adj at test print reading
Details To adjust the offset of M color test print reading signal at Auto Adjust Gradation (Full Adjust).
When replacing the Main Controller PCB / clearing the RAM data, enter the value of service label.
As the greater value is set, the image after adjustment gets darker.
Use case When replacing the Main Controller PCB / clearing RAM data
Adj/set/operate method Enter the setting value (switch negative / positive by * key) and press Apply key.
Caution After the setting value is changed, write the changed value in the service label.
Display/adj/set range -32 to 32
Default value 0
OFST-P-C
Title C density adj at test print reading
Details To adjust the offset of C color test print reading signal at Auto Adjust Gradation (Full Adjust).
When replacing the Main Controller PCB / clearing the RAM data, enter the value of service label.
As the greater value is set, the image after adjustment gets darker.
Use case When replacing the Main Controller PCB / clearing RAM data
Adj/set/operate method Enter the setting value (switch negative / positive by * key) and press Apply key.
Caution After the setting value is changed, write the changed value in the service label.
Display/adj/set range -32 to 32
Default value 0
OFST-P-K
Title Bk density adj at test print reading
Details To adjust the offset of Bk color test print reading signal at Auto Adjust Gradation (Full Adjust).
When replacing the Main Controller PCB / clearing the RAM data, enter the value of service label.
As the greater value is set, the image after adjustment gets darker.
Use case When replacing the Main Controller PCB / clearing RAM data
Adj/set/operate method Enter the setting value (switch negative / positive by * key) and press Apply key.
Caution After the setting value is changed, write the changed value in the service label.
Display/adj/set range -32 to 32
Default value 0
■ VIFADJ
COPIER > ADJUST > VIFADJ
Item Description
DEV-HV-Y
Title Adjustment of developing bias setting value (Y)
Details To adjust the setting value of Y-color developing bias.
Use case When an image failure occurs
Adj/set/operate method Enter the setting value (switch negative / positive by * key) and press Apply key.
Display/adj/set range -5 to 5
Default value 0
8. Service Mode
270
