Enhanced image stabilization is achieved by replacing the conventional transfer roller with the transfer pad. The characteristic of
the pad transfer method is:
• It maintains the wider nip to the photosensitive drum to increase transferability.
The figures below show the difference between the pad transfer method and the conventional roller transfer method schematically.
ITB
Transferroller
Photosensitivedrum
Transferpad
Narrownipwidth
Widernipwidth
<Padtransfermethod><Rollertransfermethod>
2. Technical Explanation
40
