THS – FI022GB2K8v3 --- V - MAINTENANCE
74
Remote Possible settings Standard setting Parameter
BIN_ABS input
IA
NC / NO NO
Global
Description Models
Type of device connected to the “BIN_ABSENT” input
NC: Normally Closed; NO: Normally Open.
If set to NO the Metal Detector gives an alarm when the BIN_ABSENT input is closed.
If set to NC the alarm is given when the input is open.
All models
Remote Possible settings Standard setting Parameter
EJ_CONF input
IE
NC / NO NO
Global
Description Models
Type of device connected to “Ejection confirmation” input
NC: Normally Closed; NO: Normally Open
If set to NO the Metal Detector read an “Ejection confirmation” when the EJ_CONF input is closed. If set to NC the
confirmation is given when the input is open.
All models
Remote Possible settings Standard setting Parameter
PHOTO input
IP
NC / NO NO
Global
Description Models
Type of device connected to the “Photocell” input
NC: Normally Closed; NO: Normally Open
If set to NO the Metal Detector read the passage of a pack when the photocell input is closed. If set to NC the
passage is read when the input is open.
All models
Remote Possible settings Standard setting Parameter
FOLL_CONV. input
IW
NC / NO NO
Global
Description Models
Type of device connected to the "FOLL_CONV" input
NC: Normally Closed; NO: Normally Open
If set to NO the Metal Detector stops when the FOLL_CONV input is open.
If set to NC the stop is happening when the input is closed.
All models
Remote Possible settings Standard setting Parameter
LOW_PRESS. input
I1
NC / NO NO
Global
Description Models
Type of device connected to the "LOW_PRESSURE" input
NC: Normally Closed; NO: Normally Open
If set to NO the Metal Detector gives an alarm when the LOW_PRESSURE input is closed.
If set to NC the alarm is given when the input is open.
All models
Remote Possible settings Standard setting Parameter
PHOTO Alarm
PA
ON / OFF ON
Global
Description Models
Enabling of photocell alarm
If set to ON, in case of photocell fault (continuously activated), the system goes into malfunction mode. If set to OFF,
the system does not
go into malfunction mode.
If the photocell is in a continuously active state for a long period, this is interpreted as a malfunction of the sensor by
the self-diagnosis system. There are many possible causes (wrong position, short-circuited wiring etc.)
On systems without encoder or with the Control Power Box, it is the installer’s and operator’s
responsibility to ensure that material does not remain in front of the photocell when the belt is
stopped: if it does, the photocell will be continuously active even though it is not malfunctioning. If
the foregoing situation can not be avoided, it is advisable to disable photocell self-diagnosis.
All models
Remote Possible settings Standard setting Parameter
Conf. Ejec. Al.
CE
ON / OFF OFF
Global
Description Models
Enabling of “Confirm ejection ” alarm
If set to OFF, the confirm ejection is deactivated.
If set to ON, after activation of the ejection relay, the status of the “confirm ejection” input is checked; if, after time CT
(hundredths of a second), the input has not been activated (see parameter IE), the “fault ejection” is activated. This
may be caused by the failure to move a contaminated pack into a storage container. The fault relay is activated if the
input remains active for a few seconds – e.g. a package is jammed. The alarm is reset by pressing the
key.
All models
