8-18

Cisco SCE8000 Software Configuration Guide, Rel 3.1.6S

OL-16479-01

Chapter 8 Raw Data Formatting: The RDR Formatter and NetFlow Exporting

Disabling the Linecard from Sending RDRs

The silent command disables the linecard from issuing data records. Both RDRs and NetFlow export

packets are suppressed.

Use the no form of this command if you want the linecard to send records.

Step 1 From the SCE(config if)# prompt, type silent and press Enter.

To enable the linecard to produce data records, use the following command:

Step 1 From the SCE(config if)# prompt, type no silent and press Enter.
