4-3

Cisco SCE8000 Software Configuration Guide, Rel 3.1.6S

OL-16479-01

Chapter 4 Utilities

Working with SCE Platform Files

How to List the Files in the Current Directory

Step 1 From the SCE# prompt, type dir and press Enter.

How to List the Applications in the Current Directory

Step 1 From the SCE# prompt, type dir applications and press Enter.

How to Include Files in Sub-Directories in the Directory Files List

Step 1 From the SCE# prompt, type dir -r and press Enter.

Working with Files

• How to Rename a File, page 4-3

• How to Delete a File, page 4-3

• Copying Files, page 4-4

• How to Display File Contents, page 4-5

• How to Unzip a File, page 4-5

How to Rename a File

rename

Step 1 From the SCE# prompt, type rename current-file-name new-file-name and press Enter.

How to Delete a File

delete

Step 1 From the SCE# prompt, type delete file-name and press Enter.
