5-4
Cisco SCE8000 Software Configuration Guide, Rel 3.1.6S
OL-16479-01
Chapter 5 Configuring the Management Interface and Security
Configuring the Management Port Physical Parameters
Interface State Relationship to Speed and Duplex
The following table summarizes the relationship between the interface state and speed and duplex.
Note • It is not possible to set one parameter to "Auto" and to specify the other parameter. If either speed
or duplex is set to "Auto", then both parameters will behave as if set to "Auto".
• Due to the nature of the interface, 1000Mbps operation is only available when auto-negotiation is
enabled.
How to Configure the Speed of the Management Interface
Options
The following options are available:
• speed — speed in Mbps of the currently selected management port (0/1 or 0/2):
–
10
–
100
–
auto (default) — auto-negotiation (do not force speed on the link)
If the duplex parameter is configured to auto, changing the speed parameter has no effect.
Step 1 From the SCE(config if)# prompt, type speed 10|100|auto and press Enter.
Specify the desired speed option.
Configuring the Speed of the Management Interface: Example
The following example shows how to use this command to configure the Management port to 100 Mbps
speed.
SCE(config-if)#speed 100
Table 5-1 Interface State Relationship to Speed and Duplex
Speed Duplex Actual FE Interface State
Auto Auto Auto negotiation
Auto Full/Half Auto negotiation
10/100 Auto Auto negotiation
10 Full 10 Mbps and full duplex
10 Half 10 Mbps and half duplex
100 Full 100 Mbps and full duplex
100 Half 100 Mbps and half duplex
