All content © 2017, cmotion GmbH. All specications subject to change without notice. http://www.cmotion.eu
109/112
8.5. LED Status cvolution hand unit
LED Status hand unit Status Solution
READY LED OFF
hand unit o
Turn on system
GREEN
hand unit on
RED Blinking Battery low Change battery
RED
at startup: hand unit
not ready
RUN LED OFF No run signal from
camera
Camera in standby
Check cable
Check if RUN SIMUL
is ON
GREEN Camera running OK
RED Camera error
Camera changing
speed
Slider LED(s)
OFF System idle
GREEN Lens limits have been
set
Remove lens limits
by pressing „LENS“
button
RED Motor controlled by
slider is missing or is
being controlled by
another module
Connect motor to
appropriate jack on
camin
Change slider con-
guration to dierent
motor
Blinking RED/GREEN Calibrating Wait for calibration to
nish
Blinking GREEN Calibration armed Release “CAL” but-
ton to calibrate
KNOB LEDs OFF System idle
MIDDLE LED GREEN Manual focus match-
es cfocas range
nder value
RED LED BAR Indicates focus cor-
rection is necessary
