3.2.2. Changing CLM-4 gears
Most motors have user-exchangeable gears for dierent lenses. With the CLM-4 you can
change the gears by follow these steps:
■Use a coin or at blade screwdriver to loosen the screw.
■Choose the gear with the correct gear pitch.
■Choose the side on which you would like to gear ring to be placed.
■Align the gear shaft with the gear mount and gently push the gear into the mount
until it clicks into place.
■Tighten the screw securely before use
