3.3.2. Mounting the cstrap
The cstrap is a carry-strap that can be attached to the base of the cvolution hand unit. The
strap can be worn around the neck to prevent the operator from dropping the unit, or worn over
the shoulder between shots. The fastener is designed to enable the units to rotate freely without
the risk of unscrewing.
■Hold the wide part of the pin between your index and middle nger. Insert the tip
of the locking pin into the hole located next to the CAL button on your hand unit.
Now apply pressure to the other end of the pin and push it all the way into the
hole.
■Ensure the fastener is secure before letting go of the cvolution hand unit.
