1.9.1. Connectors, Buttons and
Display of the cvolution zoom
Connectors
CBUS
The zoom module has one male and one female CBUS connec-
tor. This allows the zoom unit to be mounted to the hand unit
and/or cabled to the camin.
Buttons
ZOOM MENU BUTTON Menu – access menu/select
ZOOM MENU BUTTON UP User button, to be assigned as ZAP, LENS, REC, RET, MARKER,
SPD UP or SPD DOWN, (and navigate through menu)
ZOOM MENU BUTTON DOWN User button, to be assigned as ZAP, LENS, REC, RET, MARKER,
SPD UP or SPD DOWN (and navigate through menu)
LENS / USER BUTTON 1 (for latest revi-
sion units from 2015)
User button, to be assigned as ZAP, LENS, REC, RET, MARKER,
SPD UP or SPD DOWN
LENS / USER BUTTON 2 (for latest revi-
sion units from 2015)
User button, to be assigned as ZAP, LENS, REC, RET, MARKER,
SPD UP or SPD DOWN
Display
Bar graph (middle) Shows zoom position
Zoom speed read out (right) Shows zoom speed
Data (top center) Zoom value, Distance and lens data
USER BUTTON 1 (left / top) Shows user button 1 conguration
USER BUTTON 2 (left/bottom) Shows user button 2 conguration
Note: The zoom display is independent from the hand units display and
menu.
1.9.2. TechnicalSpecicationscvolution zoom
General
■Temperature range: -20 °C to +50 °C
■Power Supply: 9-35 V
■Weight: 163 g (5 3/4 oz)
■180 g (6.35 oz) (for revision units before 2015)
■145g (5.11 oz) (pan-bar zoom with clamp)
■143 g (5 oz) (steady zoom with clamp)
