1.10.1. Connectors, Buttons and
LEDs of the cvolution knob solo
Connectors
CBUS
The knob solo features a CBUS connector. The knob solo can
be connected directly to a cvolution camin or an ARRI ALEXA
PLUS.
Buttons/Switches
F/I/Z Switch Select Focus/Iris/Zoom scale.
L/R Switch
Select knob direction.
LENS Set lens limits
LEDs
OFF System idle
MIDDLE LED GREEN Manual focus matches cfocas range nder value
RED LED BAR Shows necessary focus correction
1.10.2. TechnicalSpecicationscvolution knob solo
General
■Temperature range: -20 °C to +50 °C
■Power Supply: 9-35 V
■Weight: knob solo basic 350 g (approx. 12 oz) knob solo adv 400 g (approx. 14 oz)
