Control Station Duetto Program interface
2.0/0518 131
Indication of input messages
Further information about input messages can be found on page 129.
Configuration CCT 800
Go to: Inputs > Input message
Right-click on the desired input and select “Add input message”.
Go to: Inputs > Input message > tab Triggering
In the drop-down lists Break, 15k, 5k6, 1k5 and Short, the desired switch steps for the respective
input level can be selected that will be shown at a control desk in the display and/or with the buzzer.
Go to: Inputs > Input message > desired input > tab Control Desks
Right-click and select the desired control desk via “Add Control Desk”.
Line fault monitoring for an Intercom station
A line fault monitoring can be configured for each subscriber that is assigned to the DUETTO control
desk. At a line fault, an input message is stored and indicated at the DUETTO control desk. Further
information about input messages can be found
on page 129.
Configuration CCT 800
A call request has to be configured for each subscriber with line fault monitoring. For this call re-
quest, the checkbox Line fault must be activated at Subscriber > Call Request > desired sub-
scriber > tab Control Desks (see page 130)!
Go to: Subscriber > Call Request > tab Parameter
Line-monitoring: Activate this checkbox to enable the line monitoring function for the respective
subscriber.
Snapshot at line-fault: Activate this checkbox to save a snapshot at a video stations when a line
fault occurs.
Go to: Subscriber > Station Properties > tab Common
Line-monitoring - delay time [s]: In this drop-down list, the delay time can be selected, after which
a line fault is triggered and indicated at the control desk.
ATTENTION: Restrictions
A maximum of 509 input messages can be configured for each input/output card!
GOOD TO KNOW: Additional input message functions
Additional input message functions can be found in the manual “Intercom Server Con-
figuration”.
NOTE: Further information
Further information about the configuration of snapshots can be found in the manual “Video WS”.
GOOD TO KNOW: Additional functions for line fault monitoring
Additional functions for line fault monitoring can be found in the manual “Intercom Serv-
er Configuration”.
