Web interface – Customization Control Station Duetto
72 2.0/0518
Action: In this drop-down list, an action can be selected that will be executed as soon as the
selected event occurs and the condition (if selected) is fulfilled. The following actions are available:
Action > Notification Function
Notification dialog
Displays the notification on the display of DUETTO that has been entered in
the field Notification dialogue Message.
PIN code dialog
Shows the PIN code dialogue through which the display of the DUETTO
device can be locked. In the field Notification dialogue message, an
optional message can be entered that will be shown in the PIN code field of
the PIN code dialogue. The required PIN code to unlock the display can be
configured through the event PIN code entered (
see above). An example
of how to configure a proper PIN code dialogue can be found on page 139.
Suppress PIN code dialog
Suppresses the PIN code dialogue on the display of the DUETTO device. An
example of how to configure a proper PIN code dialogue can be found
on
page 139.
Action > Network Function
Start broadcast
The DUETTO device sends audio signals to SIP devices (receivers) for audio
output (e.g. PA). The Real-time Transport Protocol (RTP) is used for audio
transport over multicast.
The following settings are available
:
Receiver address: In this field, enter the multicast or unicast IP address
and port (divided by a colon) through which devices can receive the multi-
cast (224.0.0.0/4 to 239.255.255.255/4). These parameters must match all re-
ceivers of this multicast.
Label: In this field, enter the desired label you wish to indicate on the dis-
play of the sending DUETTO when the multicast is executed.
Audio codec: In this drop-down list, select the desired audio codec for the
audio transmission via the multicast.
Acoustic feedback before broadcast: Activate this checkbox to stream
a gong when initiating the multicast.
Acoustic feedback after broadcast: Activate this checkbox to stream a
gong after the multicast has been terminated.
ATTENTION: The receivers must listen on the receiver address using the Real-
time Transport Protocol (RTP) and support the codec selected for broadcast
transmission (either G.722, PCMA or PCMU)!
NOTE: To configure DUETTO as a multicast receiver, see page 90.
HTTP GET
Sends a command with the HTTP GET method to the destination entered in
the field URL (e.g. control a door opener in a third-party system).
HTTP POST
Sends a command with the HTTP POST method with the parameter POST
parameter that has been entered in the field URL (e.g. to switch on video
URL on an IP monitor).
Action > Phone/SIP Function
Phone call
Initiates a call to the SIP subscriber whose SIP number or URI has been
entered in the field Phone number.
Terminate phone call
Cancels an active SIP call.
Send DTMF tone
Sends DTMF tones to the connected devices. In the field „Send only to
phone number“, a specified device can be determined.
Open SIP door
Sends SIP-commands to open SIP-doors.
Toggle phone DND
Toggles the DND mode (“Do not disturb”) on the DUETTO device
(see page 96
).
Action > Intercom Function
Intercom call
Initiates a call to the Intercom subscriber whose call number has been
entered in the field Phone number.
Terminate Intercom call
Cancels an active Intercom call.
