Figure 4-29. Locating slots on the riser board
Table 4-3
Riser Board Components
Number Component
Primary PCI bus slot 1 (32-bit)
Primary PCI bus slot 2 (32-bit)
Secondary PCI bus slot 3 (64-bit)
Secondary PCI bus slot 4 (64-bit)
Secondary PCI bus slot 5 (64-bit)
Secondary PCI bus slot 6 (64-bit)
