Compaq PROLIANT ML370 User Manual

SCSI Cabling Instructions 5-7
Compaq Confidential – Need to Know Required
Writer: CDresden Project: Compaq ProLiant ML370 Setup and Installation Guide Comments:
Part Number: 120137-002 File Name: f-ch5 SCSI Cabling Instructions Last Saved On: 12/10/99 12:28 PM
Connecting an Array Controller to
Hot-Plug Drives
Connecting a Controller Board to the Hot-Plug
Drive Cage
ProLiant ML370 servers use an integrated SCSI array controller to run hard
drives and other system resources. The following adapter and controllers are
available from Compaq authorized resellers:
 Smart Array 221 Controller
 Smart Array 3200 Controller
 Smart Array 4200 Controller
 64-Bit Dual Channel Wide Ultra2 SCSI Adapter
The figure below shows a Smart Array 3200 Controller connected to the drive
cage in the ProLiant ML370 tower model. The Smart Array 3200 Controller
has two SCSI buses that may be configured as both external, both internal, or
one internal and one external.
CAUTION: Refer to the user documentation included with each array controller
option kit for detailed instructions, precautions, and guidelines for cabling and
system configuration requirements.
