3-16 Compaq ProLiant ML370 Setup and Installation Guide
Compaq Confidential – Need to Know Required
Writer: Gilbert Saldivar Project: Compaq ProLiant ML370 Setup and Installation Guide Comments:
Part Number: 120137-002 File Name: d-ch3 Installing the Rack Model Last Saved On: 12/13/99 3:43 PM
9. Adjust the inner slide to line up with the other two screw holes  , one at
a time, through the slotted opening in the inner slide. Use two more
8-32 x ¼-inch slotted screws
 to fasten the bracket rail to the mounting
bracket.
Use a total of five 8-32 x ¼-inch slotted screws to fasten the bracket rail
to the mounting bracket. When all five screws are fastened, the
mounting brackets and bracket rail form a mounting bracket slide
assembly ready to attach to the rack.
The screws line up with the 22-inch markings stamped along one edge
of the mounting bracket. These marks identify the mounting holes for
the 22-inch slides used in Compaq racks. The 24-inch markings stamped
along the other edge are for use with the 24-inch slides that support
other components.
10. Repeat Steps 5 through 8 for the other bracket rail and mounting
bracket.
Attaching the Slide Assembly to the Rack
WARNING: To reduce the risk of personal injury or damage to the equipment,
be sure that the leveling feet are extended to the floor and support the full
weight of the rack. Each rack must be level and stable. Racks that are not
coupled together require the installation of stabilizers. This must be done before
you perform any work on the rack. See the Documentation CD for more
information about installing leveling feet and stabilizers.
Applying the Template
The template provided with the server offers an easy and reliable way to
position the server in the rack properly. Use the tabs on the template to
suspend it from the lower hole of a two-hole set of perforations in the vertical
side rails. Pencil-mark the attachment points for the mounting bracket
assemblies, the cage nuts for the faceplate thumbscrews, and the top of the
server. Use the tick marks on the rack side rails to ensure level installation of
the server. Refer to other illustrations and instructions printed on the template.
IMPORTANT: Determine the server’s place in the rack before you start installing the
mounting bracket assemblies. To remind you of the proper placement of the server in the
rack, refer to the rack building report you printed when you planned your rack
configuration. Always mount the heaviest item on the bottom of the rack and work from
the bottom to the top.
