Specifications and Connector Interfaces D-5
Compaq Confidential – Need to Know Required
Writer: Gilbert Saldivar Project: Compaq ProLiant ML370 Setup and Installation Guide Comments:
Part Number: 120137-002 File Name: l-appd Specifications and Connector Interfaces Last Saved On: 12/10/99 12:24 PM
Connector Interfaces
For the pinouts and signals of the following connector interfaces, refer to the
Documentation CD shipped with your server.
 Integrated Dual Channel Wide Ultra2 SCSI Controller on port 1
(internal and external) and port 2 (internal only)
 Hot-plug keyboard
 Mouse
 Serial (2)
 Parallel
 IDE interface for CD-ROM drive
 Diskette connector interface
 LCD connector interface
 NC3163 Fast Ethernet NIC Embedded 10/100 WOL with RJ-45
interface
 Video
