6-4 Compaq ProLiant ML370 Setup and Installation Guide
Compaq Confidential – Need to Know Required
Writer: Gilbert Saldivar Project: Compaq ProLiant ML370 Setup and Installation Guide Comments: Final approval required
Part Number: 120137-002 File Name: g-ch6 Server Configuration and Utilities Last Saved On: 12/10/99 12:26 PM
System Configuration Menu
The following options are available from the System Configuration Utility
menu:
 Hardware configuration
 Drive array configuration
 Power-On defaults
 System configuration partition
 Configuration backup
 Return to the previous menu
Configuring Hardware
After the Configure Hardware menu, a screen with five steps is displayed.
Each step is listed below with a brief explanation.
 Important System Configuration Information
This step provides an overview of the configuration process.
 Add or Remove Boards
Press Enter to view a list of the boards and options in your
configuration. You can add, move, and delete boards from this list until
it shows all the boards and options that will be installed in your system.
 View or Edit Details
This step displays an overview of current configuration settings and
installed hardware. From this screen, you can change your hardware
resource settings and many other items, including security features,
ASR, Integrated Remote Control (IRC), and boot order.
 Examine Required Switches
Find the appropriate board’s switch and jumper settings and adjust them
to match the settings displayed on the screen.
NOTE: All processor switch settings are reserved. The system automatically detects and
reconfigures switch settings for additional processors or processor upgrades.
 Save and Exit
Use this step to save the configuration update after you have made
changes.
