Installing Hardware Options 4-3
Compaq Confidential – Need to Know Required
Writer: Gilbert Saldivar Project: Compaq ProLiant ML370 Setup and Installation Guide Comments:
Part Number: 120137-002 File Name: e-ch4 Installing Hardware Options Last Saved On: 12/10/99 12:22 PM
Differences Between the Tower and Rack
Model Servers
The major difference between the Compaq ProLiant ML370 tower and rack
models is the chassis configuration. The tower model can be mounted in a
rack, however, with the Tower-to-Rack Conversion Option Kit. The tower
model also has feet on the bottom of the server and a front bezel to cover the
server chassis. In this setup and installation guide, only the tower version is
shown for most of the major hardware upgrade installation procedures.
1
2
3
4
Figure 4-1. Tower model (left) with front bezel removed and
rack model (right)
Table 4-2
Chassis Components
Number Component

Small access panel

Large access panel

Removable media area

Wide Ultra2 SCSI drive cage
