Switches and Jumpers E-3
Compaq Confidential – Need to Know Required
Writer: Gilbert Saldivar Project: Compaq ProLiant ML370 Setup and Installation Guide Comments:
Part Number: 120137-002 File Name: m-appe Switches and Jumpers Last Saved On: 12/10/99 12:24 PM
SCSI Device Jumper Settings
No two SCSI devices connected to the same SCSI controller can have the
same SCSI ID. If another SCSI device is connected to the same controller,
check its SCSI ID from the System Configuration Utility before beginning the
installation procedure for this additional drive. The SCSI ID is set by jumpers
ID 2, ID 1, and ID 0 located on each SCSI device.
The table below provides the SCSI ID jumper settings for Compaq SCSI hard
drives.
Table E-2
SCSI Device Jumper ID Settings
SCSI ID Bit 2 Bit 1 Bit 0
6OnOnOff
5OnOffOn
4OnOffOff
3 Off On On
2 Off On Off
1OffOffOn
0 Off Off Off
