Installing Additional Memory
You can expand computer memory by installing industry standard
Synchronous DRAM (SDRAM) Dual Inline Memory Modules (DIMMs) on
the system board. The following guidelines must be followed when installing
additional memory:
Use only 64-MB, 128-MB, 256-MB, 512-MB, or 1-GB modules (when
available) of 133-MHz registered SDRAM.
The DIMM sockets may be populated in any order.
CAUTION: Use only Compaq SDRAM modules. SDRAM from other sources may
adversely affect data integrity.
To install more memory, refer to one of the following installation sources:
For a text and illustrated procedure, refer to the installation
documentation that came with the option kit.
For a text overview of the procedure, refer to the procedure below.
For an illustrated overview of the procedure, refer to the hardware
installation and configuration poster shipped with your server or to the
processor cage configuration label located on the inside of the large
access panel.
Installing additional Compaq SDRAM:
1. If the computer is on, turn it off and disconnect the power cord.
2. Disconnect any other external equipment connected to the computer.
3. Open the large access panel.
4. Locate the appropriate slot on the system board.
5. Align the key slot on the bottom edge of the memory module with the
tab in the slot.
