Installing Hardware Options 4-9
Compaq Confidential – Need to Know Required
Writer: Gilbert Saldivar Project: Compaq ProLiant ML370 Setup and Installation Guide Comments:
Part Number: 120137-002 File Name: e-ch4 Installing Hardware Options Last Saved On: 12/10/99 12:22 PM
3. Loosen the front panel thumbscrews  to release the server from the
rack.
4. Pull the server out from the rack to the locked position.
5. Loosen the two thumbscrews  located on the front panel of the server.
6. Slide the large access panel toward the rear of the unit 0.5 inch (1.5 cm).
7. Lift and remove the panel  .
2
1
3
1
2
Figure 4-7. Removing the large access panel (rack server)
8. Turn the large access panel over to locate the drive configuration label.
This label provides information on installing and configuring drives,
installing memory, installing additional processors, and setting switches.
9. Set the panel to the side and use the label to locate components inside
the chassis.
