5-6 Compaq ProLiant ML370 Setup and Installation Guide
Compaq Confidential – Need to Know Required
Writer: CDresden Project: Compaq ProLiant ML370 Setup and Installation Guide Comments:
Part Number: 120137-002 File Name: f-ch5 SCSI Cabling Instructions Last Saved On: 12/10/99 12:28 PM
1
2
2
1
Figure 5-3. Default cabling configuration
In the factory configuration, the server is ready for the installation of hot-plug
hard drives in the hard drive cage. The server sets SCSI IDs automatically and
no additional cables are required.
Several optional controllers for expanding storage capacity or running arrays
are available from Compaq and Compaq authorized resellers:
 Smart Array 221 Controller
 Smart Array 3200 Controller
 Smart Array 4200 Controller
 64-Bit Dual Channel Wide Ultra2 SCSI Adapter
 Integrated Smart Array Controller
For additional information about features and installation of the Integrated
Smart Array Controller, refer to the information in the option kit and in
Chapter 4, “Installing Hardware Options.”
