NOTE: Heat sink and processor mounting hardware may appear different than illustrated.
Table 4-5
System Board Components
Number Component Number Component

SCSI port 1

Processor configuration
switch–RESERVED

SCSI port 2

System configuration
switch

Integrated Smart Array
Controller slot

Processor Power Module
slot 1 (populated)

Battery

Power supply signal
header

Power switch
connector

Power supply connectors

LCD connector

DIMM sockets

Virtual power button
connector

Processor fan header

Diskette drive
connector

Processor slot 1
(populated)

CD-ROM connector

Processor slot 2

Processor Power
Module (PPM) slot 2

Riser board slot

Slot fan header
Note: Your server is configured for the appropriate processor settings at the factory. The
system board automatically detects and reconfigures the processor switch settings when
you remove, install, or add a processor.
