Compaq PROLIANT ML370 User Manual

3-2 Compaq ProLiant ML370 Setup and Installation Guide
Compaq Confidential – Need to Know Required
Writer: Gilbert Saldivar Project: Compaq ProLiant ML370 Setup and Installation Guide Comments:
Part Number: 120137-002 File Name: d-ch3 Installing the Rack Model Last Saved On: 12/13/99 3:43 PM
Figure 3-1 ProLiant ML370 server installed in the rack
Complete rack mounting instructions are available on the Documentation CD
shipped with your server. In addition, the Rack Builder Configuration and
Rack Information Library information can be found on the Compaq website:
http://www.compaq.com
The entire Rack Resource CD Kit, part number 298721-001, ships with all
Compaq server racks. Contents for each CD include:
 Rack Builder Pro Configuration Tool
This information allows you to simulate potential Compaq rack
configurations based on your input. The rack builder tool provides:
G Graphical preview of properly configured racks
G Site planning data, power requirements, cooling mandates, and
physical specifications
G Ordering information, required components, part numbers, and
appropriate quantities
 Installing Rack Products
This information gives a visual overview of operations required to
configure a Compaq rack with rack-mountable components. The video
covers key configuration steps including:
G Site planning
G Installing rack servers and rack options
G Cabling
G Coupling multiple racks together
