3-12 Compaq ProLiant ML370 Setup and Installation Guide
Compaq Confidential – Need to Know Required
Writer: Gilbert Saldivar Project: Compaq ProLiant ML370 Setup and Installation Guide Comments:
Part Number: 120137-002 File Name: d-ch3 Installing the Rack Model Last Saved On: 12/13/99 3:43 PM
Figure 3-3. Rack mounting inner and outer brackets
NOTE: To make installation of the mounting bracket easier, attach the bracket rail to the
rack mounting bracket before attaching the mounting bracket assembly to the rack. This
way, the joined mounting bracket and bracket rail can be fastened to the rack as one
assembly.
Figure 3-4. Slide rail assembly with outer bracket rail and inner
component rail
