Introduction Engineering Manual
6
Table 1: Differences between control panel types
Panel Type
Feature M550 M600 M750 M800 M800i
D
M1000
EN50131-1/PD6662 grade
(max)
2 2 3 3 3 3
Maximum zones
1
40 40 40 40 46 144
Wards 4 4 4 4 4 8
Ward groups (part sets) 4 4 4 4 4 8
User codes 50 50 50 50 50 99
Network ports 2
2
2
2
2
2
2
2
1
3
2
2
ID Loop ports (for ID biscuits) 0 0 0 0 1 0
Digital communicator outputs 8 8 16 16 16 16
On-board transistor outputs 2 2 2 2 2 3
On-board relay outputs 1 1 1 1 1 2
On-board modem No Yes No Yes Yes Yes
CPA6 output module port No No Yes Yes Yes Yes
Serial port
4
No No Yes Yes Yes Yes
Removable terminal blocks No No Yes Yes Yes Yes
Event log entries 1000 1000 1000 1000 1000 2000
Shunt groups 5 5 5 5 5 10
The following figures illustrate the network architecture of each type of panel.
See "Compatible Devices" on page 12 for details of compatible devices, including
keypads, LECs, XNodes, MNodes, MIDNodes and IDNodes.
1
Each panel includes eight on-board zones.
2
Network 1 connects to keypads and/or LEC2s. Network 2 supports keypads, LEC2s, XNodes, MNodes or an
IDNode.
3
Connects to keypads and/or LEC2s.
4
All panels include a USB port.
