D-Link xStack DGS-3120 Series Reference Guide

xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
93
Figure 4-24 Surveillance VLAN Port Settings window
The fields that can be configured are described below:
Parameter
Description
Unit
Select the unit you want to configure. (EI and SI Mode Only)
From Port / To Port
Use the drop-down menu to select a range of port to display.
State
Use the drop-down menu to enable or disable the state of the port.
Click the Apply button to accept the changes made.
Surveillance VLAN OUI Settings
This window is used to configure the user-defined surveillance traffic’s OUI. The OUI is used to identify the
surveillance traffic. There are a number of pre-defined OUIs. The user can further define the user-defined OUIs if
needed. The user-defined OUI cannot be the same as the pre-defined OUI.
To view the following window, click L2 Features > VLAN > Surveillance VLAN > Surveillance VLAN OUI
Settings, as shown below:
Figure 4-25 Surveillance VLAN OUI Settings window
The fields that can be configured are described below:
Parameter Description
OUI Address
User defined OUI MAC address.

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
