xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
202
Network Mask
The network mask that uniquely identifies the network that corresponds to the OSPF
The type of address aggregation. Options to choose from are NSSA Ext and Summary.
Allows for the advertisement trigger to be enabled or disabled.
Click the Apply button to accept the changes made.
Click the Edit button to re-configure the selected entry.
Click the Delete button to remove the selected entry.
OSPF Host Route Settings
This window is used to configure OSPF host route settings.
To view the following window, click L3 Features > OSPF > OSPFv2 > OSPF Host Route Settings, as shown
below:
Figure 5-52 OSPF Host Route Settings window
The fields that can be configured are described below:
Parameter Description
Specifies the host’s IP address used.
Enter a metric between 1 and 65535, which will be advertised.
Area ID
Enter a 32-bit number in the form of an IP address (xxx.xxx.xxx.xxx) that uniquely
identifies the OSPF area in the OSPF domain.
Click the Apply button to accept the changes made.
Click the Edit button to re-configure the selected entry.
Click the Delete button to remove the selected entry.
OSPF Default Information Originate Settings
This window will change the status of the originating OSPF default external route.
To view this window, click L3 Features > OSPF > OSPFv2 > OSPF Default Information Originate Settings as
shown below:
Figure 5-53 OSPF Default Information Originate Settings window
The fields that can be configured are described below:
