D-Link xStack DGS-3120 Series Reference Guide

xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
112
Figure 4-45 MAC Notification Settings window
The fields that can be configured are described below:
Parameter Description
State
Enable or disable MAC notification globally on the Switch
Interval (1-2147483647)
The time in seconds between notifications. Value range to use is 1 to 2147483647.
History Size (1-500)
The maximum number of entries listed in the history log used for notification. Up to
500 entries can be specified.
Unit
Select the unit you want to configure. (EI and SI Mode Only)
From Port / To Port
Select the starting and ending ports for MAC notification.
State
Enable MAC Notification for the ports selected using the drop-down menu.
Click the Apply button to accept the changes made for each individual section.
MAC Address Aging Time Settings
Users can configure the MAC Address aging time on the Switch.
To view the following window, click L2 Features > FDB > MAC Address Aging Time Settings, as shown below:
Figure 4-46 MAC Address Aging Time Settings window
The fields that can be configured are described below:

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
