D-Link xStack DGS-3120 Series Reference Guide

xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
228
DVMRP Routing Table
This window is used to display DVMRP routing table on the Switch.
To view the following window, click L3 Features > IP Multicast Routing Protocol > DVMRP > DVMRP Routing
Table, as shown below:
Figure 5-103 DVMRP Routing Table window
The fields that can be configured are described below:
Parameter Description
Source IP Address
Enter the IP address of the Source.
Source Netmask
Enter the Netmask of the Source IP address.
Click the Find button to locate a specific entry based on the information entered.
Click the View All button to view all the interfaces configured on this switch.
DVMRP Neighbor Table
This window is used to display DVMRP neighbor table on the Switch.
To view the following window, click L3 Features > IP Multicast Routing Protocol > DVMRP > DVMRP Neighbor
Table, as shown below:
Figure 5-104 DVMRP Neighbor Table window
The fields that can be configured are described below:
Parameter Description
Interface Name
Enter the name of the interface.
Neighbor IP
Address
Enter the IP address of the neighbor.
Neighbor Netmask
Enter the Netmask of the neighbor IP address.
Click the Find button to locate a specific entry based on the information entered.
Click the View All button to view all the interfaces configured on this switch.
DVMRP Routing Next Hop Table
This window is used to display DVMRP routing next hop table on the Switch.
