xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
251
Click the View Detail link to view more information regarding the specific entry.
Click the Delete button to remove the specific entry.
Click the View Detail link to see the following window.
Figure 5-144 IP Standard Access List Settings - View Detail window
The fields that can be configured are described below:
Parameter Description
Direction
Use the drop-down menu to Permit or Deny the specified network.
Access Address
Enter the network address.
Click the Add button to add a new entry based on the information entered.
Click the <<Back button to return to the previous window.
Click the Delete button to remove the specific entry.
Route Map Settings
This window is used to create a route map or add/delete sequences to a route map.
To view the following window, click L3 Features > IP Route Filter > Route Map Settings, as shown below:
Figure 5-145 Route Map Settings window
The fields that can be configured are described below:
Parameter Description
Route Map Name
Enter the route map name.
Click the Find button to locate a specific entry based on the information entered.
Click the Add button to add a new entry based on the information entered.
Click the View All button to display all the existing entries.
Click the Delete All button to remove all the entries listed.
Click the View Detail link to view more information regarding the specific entry.
Click the Delete button to remove the specific entry.
Click the View Detail link to see the following window.
