D-Link xStack DGS-3120 Series Reference Guide

xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
215
Click the View Detail link to view more information regarding the specific entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Click the View Detail link to see the following window.
Figure 5-84 OSPFv3 LSDB Link Detail Table window
Click the View Detail link under Prefix Information to view more information.
Click the <<Back button to return to the previous window.
Click the View Detail link to see the following window.
Figure 5-85 OSPFv3 LSDB Link LSA Prefix Detail Table window
Click the <<Back button to return to the previous window.
OSPFv3 Neighbor Table
This window is used to display OSPFv3 neighbor information.
To view the following window, click L3 Features > OSPF > OSPFv3 > OSPFv3 Neighbor Table, as shown below:
Figure 5-86 OSPFv3 Neighbor Table window
The fields that can be configured are described below:
Parameter Description
Interface Name
Enter the IP interface name where the neighbor is built.
Neighbor IP Address
Enter the router ID of the neighbor.
Click the Find button to find the specified entry.
Click the View All button to view all the entries.
OSPFv3 Virtual Neighbor Table
This window is used to display OSPFv3 virtual neighbor information.
To view the following window, click L3 Features > OSPF > OSPFv3 > OSPFv3 Virtual Neighbor Table, as shown
below:

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
